| Performance properties |
Operational temperature range |
-30°C up to +70°C
|
|
|
Peak temperature endurance |
up to +80°C
|
||
|
Temperature accuracy (guaranteed)1) |
1°C | ||
| Temperature accuracy (typical)1) | <1°C | ||
| Temperature precision (guaranteed)2) | ±0,4°C | ||
| Temperature precision (typical)2) | ±0,3°C | ||
| Temperature resolution | 0,1°C | ||
| Temperature sensitivity | 10pm/°C | ||
| Ingress Protection rating | IP66 | ||
| Physical properties |
Housing material |
PEEK
|
|
| Dimensions (without cable)3) | Ø2 mm x 26 mm | ||
| Weight (without cable) | 0,1g | ||
| Cable length4) | 1mtr | ||
| Cable Bend Radius (dynamic) | 60mm | ||
| Cable Bend Radius (static) | 30mm | ||
| Connector type5) | FC/APC | ||
| Packaging | Cardboard box with dimensions: 370x290x45mm | ||
| Quality Statement | DTP-02 sensor is compliant with IEC 61757:2018 All sensors are 100% tested and calibrated at SYLEX. Sensor is manufactured according to ISO 9001:2008 and ISO 14001:2004 | ||
Notes:
- 1)Â Accuracy is established for each individual sensor under laboratory conditions and it includes hysteresis, non-linearity and repeatability of the sensor.
- 2)Â Precision is established on a batch basis and it includes hysteresis, non-linearity, repeatability and reproducibility of the sensor.
- 3)Â For further dimensions details see the product drawing
- 4)Â Cable length is extendable on request
- 5)Â Other connector types available on request
